Melamine Faced Plywood

DECORATIVE FACES · PLYWOOD CORE · FACTORY SUPPLY

Your furniture finish, with the plywood and processing behind it.

Bring a coordinated finish to cabinets, wardrobes, retail displays and interior panels with melamine-faced plywood made in our Xuzhou factory. Choose solid colours, woodgrain, clothgrain or marblegrain designs, then match the plywood construction to the parts you will make.

We supply full sheets, cut blanks and processed components. Send a furniture drawing, decor reference or the dimensions you know; our team will help turn them into a core, finish, sample and factory quotation.

CABINETS · WARDROBES · COMMERCIAL INTERIORS

Choose the board around the furniture you sell.

CORE · LAYUP · FITTINGS

Choose a plywood core that works at the cut edge.

Our core options include poplar, hardwood, birch and eucalyptus. Specify an all-birch construction when you need birch throughout, or identify a mixed layup and outer veneer separately. The decor can remain the same while the core changes the part’s weight, edge appearance and machining requirements.

Keep the veneer and printed pattern directions separate

Plywood uses crossed veneer directions. For a loaded shelf or demanding connection, include the panel direction, thickness and relevant construction data with the design. Mark the printed decor direction separately on the cutting list.

Inspect long-edge and cross-edge offcuts, narrow strips, grooves and edge-drilled holes from the selected board. Agree the core joints, gaps and repairs acceptable at the fitting or visible edge, then keep that cut sample with the order.

Bring the hardware, engagement length, edge distances and required loading with the component drawing. A drilled and assembled piece connects the panel choice to the actual joint. See the European Panel Federation plywood overview for a material reference.

COLOUR · TEXTURE · REVERSE · EDGE

Make every visible side part of one finish choice.

Choose solid colours, woodgrain, clothgrain or marblegrain with the texture and sheen your furniture needs. Browse the melamine colour catalogue, then send the decor code or finish reference you want to match.

Keep woodgrain direction and neighbouring fronts together in the cutting schedule. For tall doors or long dividers, include the face-and-back construction, support and storage conditions with a full-size part for reviewing flatness.

Compare white, black, woodgrain and double-sided melamine plywood. If you want a real wood face for staining or clear coating, see natural oak veneer plywood. For HPL, send the laminate type, thickness, adhesive and balancing reverse so we can quote that build-up.

THREE FORMATS · CUTTING YIELD

A small width change can save a whole row of boards.

Our standard formats are 1220 × 2440, 1250 × 2500 and 1500 × 3000mm. Compare the sheet against your longest part, printed pattern direction and machine capacity.

For 610 × 730mm blanks, two across with a 3mm kerf need 1223mm. With 10mm trimmed from each outside edge, a 1220mm sheet has 1200mm usable width, while a 1250mm sheet has 1230mm. That extra width changes the layout from one column to two, with 7mm remaining.

Send your cutting list for a layout around the actual panels and matched furniture sets. Include component orientation and machine limits with the sizes.

SAWN BLANK · PREPARED CORE · FINISHED PART

Get the finished size right before the first cut.

For a 611 × 731mm finished part with a net 1.0mm addition at each edge, the prepared plywood is 609 × 729mm. Removing 0.5mm from every sawn edge for preparation starts that part at 610 × 730mm.

Use the actual net edge build-up

Measure the completed band-and-adhesive process from prepared core to finished outside edge. Nominal band thickness alone does not define that addition. Identify any edge with a different band, exposed finish or no band before calculating the blank.

Keep the hole datum with the machining stage

With that 1.0mm net build, a hole centre 37.0mm from the finished left edge lies 36.0mm from the prepared core edge, or 36.5mm from the sawn edge before the 0.5mm preparation cut. Use the position required by your fitting, and name the face and edge datum so left and right parts stay correctly handed.

Plan the process tolerance around the finished part

In the dimension worksheet, a prepared width of 609.0 ±0.2mm and an addition of 0.9–1.1mm at each edge gives a finished width of 610.6–611.4mm. Set the finished acceptance limit on the order drawing and allocate the cutting, preparation and banding tolerances to meet it.

If core repair or extra trimming changes the prepared size, update the final dimensions, hole datums and edge process together.

CUT · PREPARE · EDGE · FIT

Bring the face, plywood and hardware into one machining trial.

Use the ordered thickness, core and decor for a straight cut, crosscut, groove, banded corner and critical fitting. This checks the visible face and veneer construction on the same furniture part.

For edge-drilled connectors, keep alignment, engagement, hardware and any loading or repeated-assembly trial with the chosen core. Record the completed size after all edge operations.

FURNITURE USE · MOISTURE · CLEANING

Choose the bond and finish for where the furniture works.

Our range includes melamine-based and WBP phenolic bonding options. Choose the adhesive and plywood bond with the intended use, separately from the decorative melamine face.

For wet or exterior service, send the installation and exposure so our team can plan the complete face, core and protective detail. Explore waterproof melamine plywood for that route. For a fibreboard construction, compare moisture-resistant melamine MDF with its own machining and core requirements.

PANEL DATA · CONSTRUCTION · TEST METHOD

Keep the technical record with the plywood you choose.

The product moisture guide is 10–15%; the panel data record below reports 5.8% against a 4–13% criterion. Set the delivery moisture target, conditioning and measurement method with the selected core and order.

For load, hardware, surface or emission requirements, send the property and method your project needs. Our team will help match the relevant data to the plywood construction, thickness and intended component.

The order defines the required construction and acceptance values. For shipment weight, use its actual dimensions and density, then add packing and supplied fittings.

SHEETS · CUT PARTS · PACKED SETS

Check the details that will be hidden after assembly.

Keep the core, thickness, decor batch and drawing reference with the inspection record. Inspect before banding or hardware conceals the cut edge, groove or connection.

Measure the supplied condition

State whether thickness includes both decorative faces, where readings are taken and the conditioning state. At 9mm, select one tolerance in the quotation from the listed thickness bands. Use the agreed final-part dimensions, support and flatness method when checking processed components.

Protect the finish through delivery

Store packs on a level, supported base in dry, protected conditions. Keep separators clean, protect corners and spread restraint loads. Record receiving damage with identifiable parts and follow the selected material’s conditioning requirements before machining.

Our production and inspection service can connect dimensional checks, packing photos and part records to your order.

COLOUR FIRST · WORKING CORNER NEXT

Try the part your workshop will actually make.

For tall panels, add a useful size to review handling and flatness. For furniture near water, include the actual edge, opening or joint. Keep the accepted decor, core, thickness, face designation and drawing revision with the production order.

Standard samples without special work or a logo have no sample charge; delivery is separate. Send the drawing and purpose for a custom processed sample.

PRODUCT REPORTS · ORDER RECORDS

Give your purchasing team the documents for the chosen supply.

The SGS report linked below covers 18mm natural hardwood plywood with melamine paper facing as configuration A and film paper facing as configuration B. Use configuration A when reviewing the melamine-faced route, and keep the facing and core identity with its results.

Send the required certificates, emission method or component criteria with your destination and panel specification. We can help connect product reports, the accepted sample, drawing revision, inspection records and packing documents to that order.

Keep any management-system certificate with the supplier information, and each product test with its identified construction. For other cores or thicknesses, include the required data in the enquiry so our team can arrange the appropriate document set.

FULL SHEETS · CUT BLANKS · PROCESSED PARTS

Get a factory quote around your next furniture order.

Start with a drawing, finish reference or known dimensions. Send the core and thickness, sheet or finished-part sizes, decor and reverse, quantity and destination. Include the operations you want supplied and our team can help complete the remaining details.

Available to order. Production takes 10–15 days, with container shipping and freight terms arranged for your order. Our after-sales warranty is 180 days.

Send your drawing or decor reference to sales@plywoodsupplier.cn, or use the quotation form.

PRODUCT-SPECIFIC QUESTIONS

Questions about Melamine Faced Plywood
